HOT HOT EURO IV 330 HP ENGINE CHINESE NORTH BENZ 6*2 TRUCK 8 CUBIC METERS CONCRETE MIXER BOTTOM PRICE FOR SALE
| 8X4 North Benz concrete mixer truck 31ton 12 wheels Beiben vertical concrete mixer | |||
| Drive Model | 4X2 6X4 6X2 8X4 | ||
| Vehicle Main Dimensions | (L x W x H)mm | 11820*2500*3500 | |
| Wheel base (mm) | 1500+4750+1450 | ||
| Wheel track (front/rear) (mm) | 1400/2900 | ||
| Weight in KGS | Curb Weight | 15000 | |
| G.V.W. | 30000 | ||
| Max. driving speed(km/h) | 85 | ||
| Engine | Brand | Weichai | |
| Model | WD615.50 | ||
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | ||
| Horse Power(HP) | 280 | ||
| Displacement | 9.726L | ||
| Max. Output Power | 206KW | ||
| Emission standard | Euro II | ||
| Gearbox | 5S-111GP 9forwards& 1 reverse | ||
| Clutch | Reinforced diaphragm clutch, diameter 430mm | ||
| Tire | 11.00-20,12.00-20,12.00-22.5,All steel radial tire, 1pc including 1 spare tire | ||
| Brakes | Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake | ||
| Mixer Drum | |||
| Volume | 8CBM 9CBM 10CBM 12CBM 13CBM 15CBM 20CBM 25CBM 30CBM 35CBM | ||
| Water Supply Patterns | Air Pressure | ||
| Material | Q235/Q345/610L/Q700 carbon steel, stainless steel, alloy steel | ||
| Thickness | 12 13 14 15 16mm | ||
| Tilt(°) | 11°-13° | ||
| Rotation Speed(r/m) | 0-18 | ||
| Material Discharging Speed | 3(M3/min) | ||
| Material Remanining Ratio | ≤0.6% | ||
Product Description
| Chassis | ND1240L35J | |
| Load Parameters | ||
| G. V. W. (kg) | 24000 | |
| Curb weight, toal (kg) | 12350 | |
| Loading capacity (kg) | 11520 | |
| Drive type | 6*2 | |
| Max. speed KM/h | 93 | |
| Front axle capacity(KG) | 7000 | |
| Rear axle capacity (KG) | 7000,/10000 | |
| Leaf spring | 12/12/8+6 | |
| Tyre | 12.00-20,12.00R20,11.00-20,11.00R20, | |
| Appr/Dep.:(°) | 26/17 | |
| Dimension Parameters | ||
| Dimension(mm) (L*W*H) | 8650*2500*3800 | |
| Wheel base(mm) | 1500+3550 | |
| Wheel trace(mm) | 2045/2045,1800 | |
| Drum specification | ||
| Mixing volume | 6 M3 | |
| Geomeric volume of the drum | ||
| Slump | ||
| Rotational speed of the drum | ||
| Filling speed | >3m3/min | |
| Discharging speed | >2m3/min | |
| Rest rate | <5% | |
| Filling rate | ||
| HYD. system | ||
| water supply | Water supplying system could supply water and wash the inner body | |
| Configuration Parameters | ||
| Cabin | Cabin | With A/C |
| Seating capacity | 3 | |
| Engine | Brand&Model | WP 10.336 |
| Max. horsepower | 247 KW | |
| Displacment(ml) | 9726 | |
| Fuel types | Diesel | |
| Gearbox | Brand&Model | |
| Emission standard | EURO IV | |
