15000liters Beiben Concrete Mixer Trucks
1, Foton Brand, Daimler technology, 10-15CBM Capacity
2, Imported hydraulic system
3, Well stirring, high speed of feeding & discharging
4, Low oil consumption with strong horse power 336HP
Main parameter
1, Foton Brand, Daimler technology, 10-15CBM Capacity
2, Imported hydraulic system
3, Well stirring, high speed of feeding & discharging
4, Low oil consumption with strong horse power 336HP
Main parameter
10CBM North Benz Beiben Concrete Mixer Truck
1, Beiben Brand, Benz technology, 8-10CBM Capacity
2, Imported hydraulic system
3, Well stirring, high speed of feeding & discharging
4, Low oil consumption with strong horse power
2, Imported hydraulic system
3, Well stirring, high speed of feeding & discharging
4, Low oil consumption with strong horse power
Main parameter
| ehicle Parameters | truck chassis | BEIBEN |
| Curb Weight (Kg) | 13785 | |
| Payload (Kg) | 11000 | |
| Overall Dimension(mm) | 9405×2500×3980 | |
| Wheelbase (mm) | 3800+1450 | |
| Front Overhang (mm) | 1515 | |
| Rear Overhang (mm) | 2640 | |
| Max speed | 90km/h | |
| Tire Specification | 12.00-20/12.00R20 | |
| Engine Parameters | Model | WP10.290 |
| Type | Diesel 4-stoke Direct injection,6-cylinder in line, Turbo-charging, Inner cooling. | |
| Emission Standard | Euro II | |
| Max Power (KW) | 290HP(2200r/min) | |
| Max Torque | 1250 N.m | |
| Mixing Drum Parameters | Geometric Volume of Mixing Drum (m3) | 8-10 |
| Max Mixing Cubage (m3) | 8-10 | |
| Feeding Speed (m3) | ≥2 | |
| Discharging Speed (≥m3) | ≥1.0 | |
| Leftover Rate | Nearly Zero | |
| Max Rotating Speed (r/min) | 14---16 | |
| Mixing Drum Obliquity (°) | 13.5 | |
| Max Mixing Drum Diameter (mm) | φ2162 | |
| Driving System | Speed Reducer | Italian BONFILI-577L |
| Hydraulic Pump | US EATON5423-518 | |
| Hydraulic Motor | US EATON5433-138 | |
| Radiator | German AKG with Vacuum Meter | |
| Water Supply System | Water Tank Capacity (CBM) | 2 |
| Water Supply Mode | Water Pump; Pneumatic Pump |
| Chassis Technical Specification | |||
| Product Name | Bei Ben 8*4 Concrete Mixer Truck | ||
| Chassis | ND1316D35J | ||
| Fuel type | Diesel | ||
| Cabin | one and half row | ||
| Vehicle information(mm) | Overall dimensions (L×W×H) | 10550*2500*3990 | |
| Wheel base | 1500+3550+1450 | ||
| Min. ground clearance | 500 | ||
| Weight data (kg) | G.V.W | 31000 | |
| Curb weight (chassis) | 16500 | ||
| Max payload | 25t | ||
| Whole vehicle main performance | Max. speed (km/h) | 90 | |
| Max. slope of climb (%) | 30 | ||
| Engine | Model | WP10.336N | |
| Maximum power | 247kw / 336hp | ||
| Number of cylinders | 6 | ||
| Displacement (ml) | 9726 | ||
| Emission standard | Euro 3 | ||
| Gear box | Model | 9T-160 | |
| Axle | Front Load capacity (ton) | 13t(double axle) | |
| Rear Load capacity (ton) | 18t(double axle) | ||
| Suspension | Leaf spring | 12/12/13+7 | |
| Steering Wheel | left/right hand drive | optional | |
| Brake system | Service brake | Air braking | |
| Electric device | Rated voltage | 24V | |
| Tyres & Quantity | 12.00R20 &12+1 | ||
| Concrete mixer truck technology information | |||
| Mixer drum parameter | Tanker material | 16MnQ345 | |
| Fact cubage | 10~14cbm | ||
| Filling speed | ≥2.8cbm/min | ||
| Unloading speed | ≥1.2cbm/min | ||
| Discharge reside ratio | ≤0.5% | ||
| Mixer drum rotation speed | 0~12(rpm) | ||
| Driving system | Reducer | Italy Brand | |
| Hydraulic pump | Italy Brand or USA Brand | ||
| Hydraulic motor | Japanese Brand | ||
| Heat device | Made in China | ||
