Beiben 3138 cargo truck

Beiben 3138 cargo truck

  • FOB Price $ 43,000- $49,000
  • Production time 40 days
  • Payment terms T/T
enquiry
Product Details

                                                                Beiben 3138 cargo truck chassis


beiben 3138 cargo truck

 Applications:


beiben 3138 cargo truck ,also called as beiben 3138 cargo truck chassis, beiben 12 wheeler cargo truck 380 hp engine, north benz 12 wheeler truck, beiben 3138 cargo van truck,  is designed for producing beiben oil tanker truck, beiben cargo van truck, and beiben dump truck. This beiben truck chassis can  loading, transporting and discharging heavy duty material , also can be used in for earth, sand, rock and mining delivery.



china beiben 3138 truck chassis apply germany benz technology device, with extremely work performance.



The cargo truck Box material optional: Manganese steel & Carbon steel, which is safe and durable.

 Key Features:


---- North benz 3138 chassis, strong military driving system

---- Military quality assurance, Original germany benz technology

---- Extremely work service , long terms maintenance

---- Patented axle technology, with wheel reducer

---- Completely steel cabin , safety and reliable.


 Specifications:



Beiben 3138 cargo truck
General
Vehicle Brand
CEEC TRUCKS
Chassis Brand
Beiben
Overall Dimension
10500*2490*3340 mm
GVW / Kerb Weight
45,000 kg / 14,800 kg
Cab
Cab Capacity
2 persons allowed
Air Conditioner
Heating/cooling air conditioner
Engine
Fuel Type
Diesel
Engine Brand
WEICHAI
Power
380 HP (279 KW)
Displacement
9726 ml
Emission Standard
Euro 3
Chassis
Drive Type
8X4, (left hand drive)
Transmission
FAST 9 speed levers with 1 reverse
Wheelbase/No. of axle
1950+5050+1450 mm / 4
Tire Specification
12.00R20
Tire Number
10 tires and 1 spare tire
Max Speed
90 km/h
Paint
Metallic paint
Superstructure
Body Capacity
40 T-  80 T
Tilting Device
Front lifting device
Hydraulic Cylinder
China brand
Discharging model
Rear discharging
Dump Body Dimension
7600*2300*1500 mm
Thickness
Side Board: 8mm
Floor Board: 10 mm
Control panel
English or Your language
All standard accessories: basic tool kit, English manual……
Optional
** Back alarm and Camera can be equipped.
** Italy mulit-valve can be choose.
** 12.00-24 tyre, 14.00R20 tyre, 13.00R22.5 tyre avaiable.
beiben 3138 cargo truck
Beiben  3138  truck chassis , military quality assurance, with strong merdeces benz technology axle and cabin.
beiben 3138 cargo truck
Beiben NG80B new cabin, 3138 model with strong diesel 380 hp engine.
