Beiben 2534 tipping truck

FOB Price $46,000-56,000
Production time 40 days
Payment terms T/T, West union

enquiry

Beiben 70T dump truck

Function:

◆ Heavy duty Mining area

◆ Construction site

◆ Municipal road construction

◆ Transport of heavy density stone, sand, gravel,mine

Feature:

◆ Extrmely reinforced benz technology 2534 dump truck chassis.

◆ Weichai diesel 340Hp engine combined with original benz typerear axle reducer gear and differential gear

◆Continuous welding throughout body for additional strength, Full depth rear corner post with full depth rear crossmember.

◆ Enhanced Q550A U type dumper body, and the motherboard adopts variable cross-section beams.

◆ Special beiben WELLDOX and HARDOX tipper Body Design are optional

◆ 15 years great experiences on beiben dump truck upper structures designing and supplying.

Specification:

Similar key words: beiben 40 T dump truck, beiben 50 T dumper, beiben 70 T dump truck, north benz dumper, north benz 2529,2534,2538 dumper, beiben 6*4 dumper truck, beiben 6*6 all wheel drive dumper, beiben 10 wheeler dumper, beiben 12 wheeler tipping truck. North benz dump truck manufacturer.

More than 15 years great exprience on beiben 6*4 drive tipper truck manufacturer, genuine beiben dumper truck spare parts after sale service, supply best quality beiben 2534, 2538,2542 dump truck for africa customer, we endeavour the best price for beiben dump trucks, super quality for beiben dumper.

The best north benz dump truck supplier from china baotou beiben heavy duty dump trucks. The most professional beiben dump truck work experience on beiben 2527,2628,2632,3630,2629,2634,2638 dump trucks. Currently, we supply beiben LHD dump truck with 2534 cabin, beiben RHD dumper with 2534 cabin. Also beiben off road dumper , beiben mining dump trucks are also avaiable .

Beiben 2534KY dumper

Sales No.		2634GKY
Dimension（mm)	Long	8250
	Wide	2500
	High	3690
Wheel base（mm）		3800+1450
Drive		6×4
Engine	Model	WP10.340E32
Cabin		NG80B/Long cab
Clutch（mm）		Φ430
Front Axle		7.5T
Rear/Mid Axle	Model/speed radio	Double Reduction Driving Axle /5.263
Steering System		ZF8098
Braking System		Dual Circulation Air Brake System
Fuel Tank（L）		400L
Frame/mm		317×70×8.5+7+8mm
Tire		12.00R20
Front/Rear Overhang		1410/1590
Transmission		Fuller 9JS150TA
Curb Weight（kg)		12470
Up Body Volume(m³)		5.6mx2.3mx1.3m
Max Speed（km/h)		90

Beiben dump truck

Model	Engine Model	Rated Power	Payload	Driving Mode
Beiben 2538	WP10.380N	380 Hp	60 Ton	6*4
Beiben 2534 KY	WP10.340	340 hP	50 Ton	6*4
Beiben 2534	WP10.340	340 Hp	30 Ton	6x4
Beiben 2534k	WP10.340	340 Hp	36 Ton	6*4
Beiben 2538k	WP10.380	380 Hp	40 Ton	6*4
Beiben 2529	WP10.290	290 Hp	45 Ton	6*4
Beiben 2538k	WP10.380	380 Hp	40 Ton	6*4
Beiben 2538	WP10.380N	380 Hp	45 Ton	6*4
Beiben 2529	WP10.290N	290 hp	30 Ton	6*4
Power star 2628	WP 10.280N	280 Hp	40 Ton	6*4
Beiben 2629	WP 10.290N	290 Hp	40 Ton	6*4
Beiben 2634	WP 10.340N	340 Hp	35 Ton	6*4
Beiben 2629 dumper	WP 10.290N	290 Hp	35 Ton	6*4
Beiben 2629 A	WP10.340	340 Hp	40 T	6x4
Beiben 2629 A	WP10.290	290 Hp	25-30 T	6x4
