North benz 2534 dumper
-
FOB Price
$42,000-50,000
-
Production time
35 days
-
Payment terms
T/T, West union
North benz 2534 dumper
Function:
◆ Mining area
◆ Construction site
◆ Municipal road construction
◆ Transport of stone, sand, gravel
◆ Germany
BENZ technology dumper chassis with high durability and reliability
◆ Weichai diesel engine combined
with original rear axle reducer gear and differential gear
◆Continuous welding throughout
body for additional strength, Full depth rear corner post with full depth rear
crossmember.
◆ Enhanced dumper body, and the
motherboard adopts variable cross-section beams.
◆ Special
beiben Dump Body Design are optional
Best supplier of beiben 6*4 drive
dump truck, beiben 6*6 dump truck, we have more than 20 years experience in
manufacturing beiben 2527,2529,2532,2534,2538 dumper. Genuine beiben dump truck
spare parts are avaiable in 24 hours. we provide beiben 6 wheeler dump tuck,
beiben 10 wheeler dump trucks, beiben 12 wheeler earth moving tipping trucks. .
| Beiben 2534KY tipper/6×4/4450+1450/Long Cab/LHD | ||||||
|
Dimension |
9110*2500*3430mm | |||||
| Upper body inner dimension | 6500x2300x1050 sand body, Hyva hydralic lifting system,thickness: bottom 8mm, side 6mm | |||||
| Approaching angle/Departure angle | 26/45° | |||||
| Overhang(front/rear) | 1410/1800mm | |||||
| Wheel base | 4450+1450mm | |||||
| Max speed | 85km/h | |||||
| Curb weight | 12190kg | |||||
| Loading capacity | 12680kg | |||||
| Slope climbing capability | Max.40% | |||||
| Engine | Model | WP10.340E32，water-cooled，four strokes，6 cylinders in line，turbocharged, directly injection | ||||
| Displacement | 9.726L/Diesel | |||||
| Stroke | 126/130mm | |||||
| Max. power | 250/2200 (kw/rpm) | |||||
| Max.torque | 1350/1200-1600（Nm/rpm） | |||||
| Emission stantard | EuroⅢ | |||||
| Fuel tanker capacity | 300L | |||||
| Clutch | ∮430, Single dry frictional disc，Hydraulic boosting | |||||
| Gearbox | 9JS150A, mechanism,9 forward gears,1 reverse gear, manual operated, | |||||
| Gear ratio of gear box | 12.57/8.39/6.15/4.59/3.4/2.47/1.81/1.35/1.00 R:13.14 | |||||
| Suspension system | Front | Non-free standing leaf spring,telescopic shock absorber with stablizer bar suspension , 10pcs | ||||
| Rear | Non-free standing stablization spring, balance suspension system, 13pcs | |||||
| Brake system | Service brake | Brake gap can be adjusted automatically, double circulation air brake system | ||||
| Assistant brake | Engine exhaust brake | |||||
| Park brake | Potential springs pressing on middle and rear wheels | |||||
| Steering system | ZJ120D,whole circulation in ball, hydraulic booster | |||||
| Frame | Strengthened Streight beam | |||||
| Front axle (Mercedes Technology) | Double-shoe pneumatic brake, non-driving steering axle | |||||
| Middle and Rear axle (Mercedes Technology) | Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle | |||||
| Tyre | 12.00R20 Radial | |||||
| Electrical system | Battery | 2X12V/135Ah | ||||
| Generator | 28V-35A | |||||
| Starter | 5.4Kw/24V | |||||
| Cabin |
NG80B Long cabin with single sleeper ; Full steel skeleton structure, covered with double layer steel plate; Can be tipped forwardly; High back with arm seat for driver, high back seat for co-driver; With inner A/C |
|||||
Beiben dump truck
|
Model
|
Engine Model
|
Rated Power
|
Payload
|
Driving Mode
|
|
WP10.380N
|
380 Hp
|
60 Ton
|
6*4
|
|
|
WP10.340
|
340 hP
|
50 tON
|
6*4
|
|
|
WP10.340
|
340 Hp
|
30 Ton
|
6x4
|
|
|
WP10.340
|
340 Hp
|
36 Ton
|
6*4
|
|
|
WP10.380
|
380 Hp
|
40 Ton
|
6*4
|
|
|
Beiben 2529
|
WP10.290
|
290 Hp
|
45 Ton
|
6*4
|
|
WP10.380
|
380 Hp
|
40 Ton
|
6*4
|
|
|
WP10.380N
|
380 Hp
|
45 Ton
|
6*4
|
|
|
Beiben 2529
|
WP10.290N
|
290 hp
|
30 Ton
|
6*4
|
|
Power star 2628
|
WP 10.280N
|
280 Hp
|
40 Ton
|
6*4
|
|
WP 10.290N
|
290 Hp
|
40 Ton
|
6*4
|
|
|
WP 10.340N
|
340 Hp
|
35 Ton
|
6*4
|
|
|
WP 10.290N
|
290 Hp
|
35 Ton
|
6*4
|
|
|
WP10.340
|
340 Hp
|
40 T
|
6x4
|
|
|
WP10.290
|
290 Hp
|
25-30 T
|
6x4
|
Watch Beiben 2534 dumper on YOUTUBE.
Beiben 2534 dump truck in testing: https://youtu.be/0N0Vik8PBjMhttps://youtu.be/gAqsvypVe-w
BV people inspected the beiben 2534 dumper https://youtu.be/tGeePIcJals
https://youtu.be/KyshwIJ7iYY
https://youtu.be/7i2lPZ3e4Pw
How to to build a good quality beiben dump truck ?
Kenya Customer use beiben tipper truck review
Success Cases
13 units beiben V3 tractor trucks are used by tanzania customer in seaport logistic
Beiben V3 tractor trucks are used by tanzania customer in dar es salaam seaport logistic. With continue good service of beiben V3 tractors on Tanzania country, we get great order from customer. Many tanzania customer even call our beiben V3 tractor truck as china benz tractor trucks. For all tanzania customer that purchase beiben V3 tractor truck, ...
