China famous brand Beiben 8 cubic meters concrete mixer truck

China famous brand Beiben 8 cubic meters concrete mixer truck

inquiry_ico
Product Details
China famous brand Beiben 8 cubic meters concrete mixer truck
 China famous brand Beiben 8 cubic meters concrete mixer truck
Product Description

Chassis Model ND52500GJBZ
Drive type 6X4
Cubic meter    8-12
Weight   Complete kerb mass(kg) 13785
GVW(kg) 25000
Dimensions LxWxH(mm) 9405X2500X3980
Front/Rear overhang(Chassis) 1515/2640
Wheel base (mm) 3800+1450
Track width(mm) 1995/1800/1800
Performance  Max.speed(km/h) 90
Approach/Departure angle(°) 23/20
Engine Brand  WEI CHAI
Model WP10.336
Power(KW/HP) 213/290
Max.Torque(N.M)/rpm 1250N.M/1200-1600rpm
Displacement(L) 9.726
Emission Standards Euro III
Transmission  Brand  Beiben
Model 9T-160
Control type Manual
Gear shift  9-forward and 1 reverse speeds
Clutch Type Single plate,diaphragm spring
Diameter(mm) φ430
Action Mechanical type,hydraulic and pneumatic operation
Braking Service brake  With dual-circuit compressed air brake
Park brake  Spring-powered Air-cut-off Brake
Auxiliary Engine Exhaust Brake
Steering  Type TAS85
Frame Dimensions(mm) 300X90X8+6+8
Suspension the number of leaf spring 10/13
Axles Front axle 7500kg
Rear axle 13000kg double reduction driving axles
Ratio 5.263
Tyres Type(Standard) 12.00-20
Fueltank Tank capacity(L) 300
Material Aluminum
Cab  Equipments  Long flat head, 1sleeper, 2-3 persons
Mixing tank Mixing volume 9CBM

China famous brand Beiben 8 cubic meters concrete mixer truck
China famous brand Beiben 8 cubic meters concrete mixer truck
China famous brand Beiben 8 cubic meters concrete mixer truck
China famous brand Beiben 8 cubic meters concrete mixer truck
China famous brand Beiben 8 cubic meters concrete mixer truck
