Beiben 2530 fuel tanker

FOB Price $41000-$47000
Production time 30 days
Payment terms T/T, West union

Product Details

Beiben 2530 fuel truck

Function:

China beiben 2530 fuel truck is normally called as beiben 2530 oil truck, beiben 2530 oil transportation truck, beiben 300 hp engine fuel bowser. North benz 2530 fuel tanker truck.

Beiben oil trucks thanks to German and Mercedes Benz technology and heritage are manufactured to the highest international standards and the strictest military quality controls.

Our prices are considerably lower than European, American and Asian competitors; including Mercedes Benz Actros
fuel tanker trucks.

Advantage:

★ Beiben oil trucks and Mercedes Benz trucks share many features such as HL7, HD7 and VL4 axles used in the Actros and Atego models.

★ the only Asian heavy duty truck company capable of providing the quality found among European and American manufacturers.

★ Beiben fuel truck and benz trucks share familiar gearboxes - ZF and Fuller Fast.

★Mercedes Benz and Weichai WD615, WP10 and WP12. They comply with Euro 2, 3 and 4; have displacements of 10 and 12 liters and HP of 270 to 480.

★Bosch Common Rail injection, the Euro 2 with linear pump, motor and brake valve MAN Exhaust (Jack-Brake), among other qualities.

★ CEEC TRUCKS 20 years experience on beiben oil truck designing and manufacring.

Specification:

More than 15 years experience on beiben oil tanker truck manufacturing, we have great advantage on designing and producing beiben 2527,2530,2534,2538 fuel tanker trucks.
CEEC TRUCKS plant have export huge quantity tanker truck upper structure to congo, ghana, algeria, ethopia, nigeria, and other africa area. we welcome beiben truck dealer

Beiben Oil Tank Truck Model	Beiben 2527 truck chassis .
General Information
Drive Mode	6x 4
Wheel base,mm	4450+1450
Overall Length,mm	9455
Overall Width,mm	2500
Overall Height,mm	3375
N.V.W,kg	25000
Tare Weight,kg	11470
Max.Traveling Speed,km/h	85
Front Overhang,mm	1410
Rear Overhang,mm	2145
Front Track,mm	1995
Rear Track,mm	1800
Min. Ground Clearance,mm	327
Fule Tank Capacity,liters	400
Tank Body	Tank Shape Ellipse Style
Capacity ,liters	*22,000*
Compartments,pcs	3
Pressure,Mpa	0.084
Outlet Pipe Diameter,mm	80
Baffles,pcs	6
Manhole No.s	3
Hose,pcs x m	2 x 6
Filling Time,min	<10
Drainage Time,min	<22
Length,mm	7400
Width,mm	2380
Height,mm	1550
Material Thickness,mm	5
Cover Thickness,mm	5
Tank Material	Carbon steel, Q235A 16Mn
Pump	80YHCB-60
Self-Suction Depth,m	6.5
Capacity ,liters/h	60
Flow Length,m	20
Flow Speed, l/min	960
Shaft Power,kw	22.5
Inlet Diameter,mm	80
Outlet Diameter,mm	60
Pressure,Mpa	0.6
Suction Time,min	<4
